Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board

  • Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board
Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board
Product Details:
Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCULP
Payment & Shipping Terms:
Minimum Order Quantity: 200kg
Price: Negotiation
Packaging Details: wooden carton
Delivery Time: 5- 20days
Payment Terms: T/T, L/C
Supply Ability: 1500 Ton per month
Contact Now
Detailed Product Description
Application: PCB Board , Circuit Board ,Printed Circuits Board Type: Double Side Or Single Side
Standard: IPC-4562,IPC9TM-650 Name: Double Sided Polyimide Fccl Copper Clad Laminate Rolls For Circuit Board
Width: 250mm,500mm Materials: Copper Foil ,PET/PI,Adhesive
High Light:

copper laminate sheets

,

copper clad sheet

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board



Products introduction

Flexible Printed circuit Board, FPC is processing substrate material, is made of flexible insulating film and metal foil.The flexible CCL, which is made of three different materials of copper foil, film and adhesive, is called three-ply flexible CCL ("3l-Fcl").Flexible CCL without adhesive is called two-ply flexible CCL ("FCCL").



Products Structure Specification



  1. 2Layer (without Adhesive) or 3Layer (with Adhesive )?

  2. Copper foil type ? ED copper foil or Rolled copper foil ?

  3. Copper foil thickness ?

  4. Width ?standard 250mm and 500mm

  5. Single side or  double side

  6. Applciation :PCB board Circuit board Printed Circuits Board



FCCL Products Structure

Products Structure

2Layer

3Layer

Single Side

ED or RA Cu

ED or RA Cu

Adhesive

PI Film

PI or PET Film

Double Side

ED or RA Cu

ED or RA Cu

PI Film

Adhesive

ED or RA Cu

PI or PET Film

ED or RA Cu

Covertly

-

Release Paper

Adhesive

PI or PET film

Bonding Sheet

-

Release Paper

Adhesive

Release film

Stiffener

-

Release Paper

Adhesive

PI or PET film

Adhesive

PI or PET film



Application

1. Electronic Products/Portable electronic products



2. PCB board,Circuit board,Printed Circuits Board



3. Aerospace equipment, navigation equipment,Aircraft instrumentation,Spacecraft.



4. Military guidance System



5. phone/mobile



6. Digital camera



7. Vehicle Satellite Orientation Device



8. LCD TV



9. Notebook computer



10. High density lines

Products Classification

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board 0



2-Layer FCCL D/S(Double side)Casting

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board 1

2-Layer FCCL D/S /Double side FCCL -Lamination type explanation

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board 2

2-Layer Double side FCCL Structure explanation

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board 3

2-Layer Double side FCCL Process flow chart

Double Sided Polyimide Fccl Copper Clad Laminate Rolls for Circuit Board 4

Details Packing:  wooden box

P.S  Keep the dry environment,and is better use it in 30days.
