Flexible Laminate Copper Foil, 0.009 - 0.035mm Thick Copper Laminate

Flexible Laminate Copper Foil, 0.009 - 0.035mm Thick Copper Laminate

  • High Light

    copper clad circuit board

    ,

    copper clad sheet

  • Application
    PCB Board Circuit Board Printed Circuits Board
  • Standard
    IPC-4562,IPC9TM-650
  • Copper Foil Thickness
    0.009mm-0.035mm
  • Color Of Copper
    Coffee,Pink,Black
  • Polyimide Thickness
    0.5 To 2.0mils Thickness
  • Laminate Structure
    Single Side And Double Sides Both Available
  • Name
    Flexible Laminate Copper Foil, 0.009 - 0.035mm Thick Copper Laminate
  • Place of Origin
    china
  • Brand Name
    JIMA
  • Certification
    UL,ROHS,SGS
  • Model Number
    Flexible Copper Clad Laminate
  • Minimum Order Quantity
    150 square meters
  • Price
    Negotiation
  • Packaging Details
    wooden carton
  • Delivery Time
    7-15days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    600000 square meters per month

Flexible Laminate Copper Foil, 0.009 - 0.035mm Thick Copper Laminate



FCCL for Flex Printed Circuits Board PCB board Circuit board



Description

SLP flexible laminates are available in a broad range of copper clad constructions using a wide variety of base dielectrics. These laminates are available in either adhesive based or adhesiveless form.

Adhesive based clads, also known as 3-layer, are made using Polyimide film and are available in sheet form with either SLP FR or LF acrylic adhesive. Also available, under the SLP Brand name, is an epoxy adhesive based 3-layer clad in roll form.

Adhesiveless clads, also known as 2-layer, are available either as double-sided using a lamination based manufacturing process or single sided utilizing cast technologSpecifications.



Quickly Introduction

  1. Deliver :depend on your quantity,usually 7 to 15days
  2. Monthly capacity :600000 square meters
  3. Our Advantage :7 Precision Coating production line
  4. Meet RoHS, REACH and other related environmental protection decrees.
  5. Base PI film : 0.5 to 2.0mils thickness;
  6. Copper foil  EDHD and RA copper both available, 1/3, 1/2, 1.0 and 2.0 oz thicknesses
  7. Adhesive : Modified epoxy adhesive, 0.5 to 0.7 mils
  8. Laminate structure : Single side and Double sides both available



Application 1.Electronic Products,Portable electronic products
2.PCB board,Circuit board
3.Aerospace equipment, navigation equipment,Aircraft instrumentation,Spacecraft.
4.Military guidance System
5.phone/mobile
6.Digital camera
7.Vehicle Satellite Orientation Device



FCCL Products Structure

     Products Structure 2Layer 3Layer
          Single Side ED or RA Cu ED or RA Cu
Adhesive
PI Film PI or PET Film
Double Side ED or RA Cu ED or RA Cu
PI Film Adhesive
ED or RA Cu PI or PET Film
ED or RA Cu
Covertly   Release Paper
Adhesive
PI or PET film
Bonding Sheet   Release Paper

Adhesive

Release film
Stiffener   Release Paper
Adhesive
PI or PET film
Adhesive
PI or PET film



 Quality

Our principal manufacturers to ensure the high quality of products in the following aspects:

Certification - All of our principle manufacturers are ISO and/or U/L and SGS (RoHS)

approved manufacturers with complete a quality control management system.

Global Reputation - All of our principle manufacturers have already exported their

products to oversea customers and/or world-renowned brands with excellent reputations.

Credit and Trust - Most of our principle manufactures have had long time business

relationship with us.

Competitive Advantage - All the products we represent have competitive advantage

in the market, in terms of technology, pricing, and/or environment protection.

Standard- All of our principle manufacturers follow industry standards. Such as IPC

standard, GB4588.



FAQ

Q1. What's your guarantee?

A: All our products have 6 months guarantee after received goods, if any quality problem can contact us.



Q2. What's your minimum order quantity?

A:The MOQ is 150 square meter



Q3. Can you provide discount?

A:Yes, it depends on the order quantity, the larger the order is, the more discount will be enjoyed.



Q4. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.
