Name: HTE RA PCB Copper Foil 76mm / 152mm Inter Dimater 0.009 - 0.09mm Thickness
Brand: JIMA Copper
SKU: RAPCB
Price: 17.00 USD
Availability: InStock

Home Products PCB Copper Foil

HTE RA PCB Copper Foil 76mm / 152mm Inter Dimater 0.009 - 0.09mm Thickness

Product Details:

Place of Origin:	china
Brand Name:	JIMA
Certification:	SGS, ISO,Reach, RoHS
Model Number:	RAPCB

Payment & Shipping Terms:

Minimum Order Quantity:	100kg
Price:	Negotiation
Packaging Details:	wooden carton
Delivery Time:	5-15 days
Payment Terms:	T/T, L/C
Supply Ability:	1000 Ton per month

Contact Now

Detailed Product Description

Purity:	99.95%	Anti Oxidation:	180 Degree 60 Minutes, 180 Days 23 Degree
Tensile Strength:	≥ 160 MPa	Application:	PCB ,Printed Circuit Board
Length Per Roll:	500 - 5000 Meter	Inter Diameter:	76 Mm，152 Mm， 3 Inch，6 Inch
Highlight:	pcb copper clad , copper sheet roll

1/3oz (0.012mm,12um)HTE RA Rolled Copper foil For PCB(Printed Circuit board) CCL

Quickly details

Thickness: 12 um,Width: 5-620 mm, Length: 500-5000 M, Inter dimater : 76 mm,152 mm, Alloy: T2,C11000,C1100,C101,Temper: H

Features:

Single side treated foil in gray or red or back. It is Suitable for Copper Clad Laminate and Printed Circuit board.Lamellar crystal structure of rolled copper foil leads to high flexibility.The etching performance Excellent .Low profile enables to make fine circuit pattern

Application:

Casting and lamination type CCL (Copper Clad Laminate),PCB(Printed Circuit board)

· Al-based CCL

· Thermal Conductive RCC

· Thermal Conductive FR-4

· High Speed Circuit Material

· RF & Microwave Circuit Material

· Rigid Polyimide

FAQ:

Q1: What's your Shelf life?

A: we accept 6 months guarantee after goods received .

Q2: do you urgent delivery ?

A: yes,urgent delivery time is 5-7 days. common leading time 35 days.

Q3: What's your minimum order quantity?

A: Our MOQ is 50 kg.

Q4: Can you supply the sample?

A: We accept A4 sample and 50 meter rolls copper foil for test.

Technical data sheet for PCB,CCL,Polyimide board,Epoxy board

Thickness		0.009-0.09mm		Width≤520mm
Item		Unit	Parameter
Thickness		MM	0.009	0.012	0.018	0.035	0.07	0.1
Grade		－	C1100	C1100	C1100	C1100	C1100	C1100
Copper content		%	≥99.95	≥99.95	≥99.95	≥99.95	≥99.95	≥99.95
Area Weight		g/㎡	80±2	107±4	160±5	311±10	623±19	890±27
Roughness	(RA)	Um	≤0.2	≤0.2	≤0.2	≤0.2	≤0.2	≤0.2
Tensile Strength(MP)	State normal	Mpa	≥380	≥400	≥400	≥420	≥430	≥450
Tensile Strength(MP)	State temper (180℃)	Mpa	≥160	≥160	≥160	≥170	≥180	≥190
Elongation(%)	State normal	%	≥0.8	≥1.0	≥1.2	≥1.3	≥1.4	≥1.5
Elongation(%)	State temper(180℃)	%	≥5	≥6	≥8	≥15	≥20	≥25
Peel strength		N/mm	≥0.8	≥1.0	≥1.4	≥1.5	≥1.8	≥2.0
High temperature oxidation resistance(180℃ 1hour)		－	Qualified	Qualified	Qualified	Qualified	Qualified	Qualified

Remark:Standard Width,520(±1)mm,accept customization.
