RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board

RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board

  • RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board
  • RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board
  • RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board
RCC 12 Mic HTE Red Electrolytic Copper Foil For Polyimide Board
Product Details:
Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC
Payment & Shipping Terms:
Minimum Order Quantity: 100kg
Price: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Elongation: ≥ 1.5% Anti Oxidation: 180 Degree 60 Minutes, 180 Days 23 Degree
Thickness: 1/2 Oz,3/4 Oz,1 Oz,2 Oz, Color: Red Or Black
Name: Polyimide Board Copper Tooling Foil , 1-2oz Copper Thin Sheet
High Light:

12 Mic Electrolytic Copper Foil

,

Polyimide Board Electrolytic Copper Foil

,

HTE Rolled Copper Foil

RCC 12 Mic HTE Red Electrolytic Copper Foil for Polyimide Board.

Polyimide Board Copper Tooling Foil , 1-2oz Copper Thin Sheet





Products Classify:

  • The ED copper foils for PCB can be divided into below parts:
  • (STD-E)- standard electrodeposited copper foil.
  • (HD-E)-high ductility electrodeposited copper foil.



Products Specification:

  • Single side side treatment in red.
  • Thickness: 12um.
  • Width: 5-1380mm.



Feature Description:

  • Perfect normal temperature storage performance.
  • High temperature anti-oxidization performance.
  • High temperature elongation performance.





Products Application:

  • Polyimide board.
  • Epoxy board.



FAQ:

Q1: What's your guarantee?

A1: All our products have 6 months guarantee after received goods, if any quality problem can contact us.



Q2: What's your delivery time ?

A2: The common delivery time is 5-35 working days. The specific delivery time depends on the items and the quantity of your order.



HTE Copper Foil with High Elongation Copper Foil at High Temperature

Thickness um 9 12 18 25 35 70

IPC 4562

4.6.3.1



Area weight g/m² 80±1 107±3 153± 215±5 285±5 585±8

IPC 4562

4.6.3.2

Roughness (RA) μm 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4

IPC 4562

4.6.9

(RZ) μm <6.0 <6.5 <8.0 <9.0 ≤10.0 <15



Copper≧

% 99.8

IPC 4562

4.6.3.1



Tensile Strength state normal Mpa >300 >300 >300 >300 >300 >280

IPC 4562

4.6.4

state temper (180℃) Mpa >15.0 >18.0 >18.0 >18.0 >18.0 >18.0
ElongationI state normal % >3.0 >3.0 >5.0 >6.0 >10.0 >10.0

IPC 4562

3.5.3

state temper (180℃) % >2.0 >2.5 >2.5 >3.0 >5.0 >5.0
Peel strength N/mm >1.0 >1.05 >1.35 >1.70 >1.8 >2.0

IPC 4562

4.6.7

High temperature oxidation resistance(200℃,

40min)

No color change Standard
Solderability Good Standard
Solderability Good

IPC 4562

4.6.12

3. Standard Width,1295(±1)mm,May according to the customer request tailor.

We test the peel strength with FR-4(Tg140) prepreg ,please reconfirm with your pp.
