18Mic Black Electrolytic Copper Foil Low Profile Good Folding Endurance

18Mic Black Electrolytic Copper Foil Low Profile Good Folding Endurance

  • High Light

    18Mic copper foil sheet roll

    ,

    JIMA ed copper sheet plate

    ,

    2N/mm Electrolytic Copper Foil

  • Tensile Strength
    ≥ 160 MPa
  • Peel Strength
    ≥ 1 N/mm
  • Foil Profile
    RA≤0.15μm,Rz≤1.7μm
  • Application
    FCCL,FPC
  • Name
    18Mic Black Electrolytic Copper Foil Low Profile Good Folding Endurance
  • Place of Origin
    china
  • Brand Name
    JIMA
  • Certification
    SGS, ISO,Reach, RoHS
  • Model Number
    EDCU-HC
  • Minimum Order Quantity
    100kg
  • Price
    negotiation
  • Packaging Details
    wooden carton
  • Delivery Time
    5-15 days
  • Payment Terms
    T/T, L/C
  • Supply Ability
    1000 Ton per month

18Mic Black Electrolytic Copper Foil Low Profile Good Folding Endurance

Good folding endurance 18 mic low profile black electrodeposited copper foil for FPC

18Mic Black Electrolytic Copper Foil Low Profile Good Folding Endurance



Specification Reference.



  • Thickness Range: 18 mic.
  • Width Range: 5~1380 mm.
  • Factory standard width is 1290mm.
  • ID: 3inch and 6inch.



Features of LP Copper Foil Products.



  1. The treated foil in black.
  2. High profile with properties of LP-S-B/R suitable for FCCL.



LP Copper Foil Products Applicable.

  • Super fine pattern FPC.



FAQ:

Q1. Length per roll?



A1:500-5000meter.



Q2.Are the package suitable For export ?



A2:Yes , it is suitable for export.



Q3.Can you provide COA?



A3:Yes , we can.





LP/Low Profile Copper Foil of Properties.

Classification

Unit Requirement Test Method
Foil Designation /   1 H M 1 IPC-4562A
Nominal thickness / 10um 12um 1/2 OZ(18um) 3/4 OZ(25um) 1 OZ(35um) IPC-4562A
Area Weight g/㎡ 98±4 107±4 153±5 228±8 285±10

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side(Ra) սm ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5

IPC-TM-650

2.3.17

Matte side(Rz) um ≤4.0 ≤4.5 ≤5.5 ≤6.0 ≤8.0
Tensile Strength R.T.(23℃) Mpa ≥260 ≥260 ≥280 ≥280 ≥280

IPC-TM-650

2.3.18

H.T.(180℃) Mpa ≥180 ≥180 ≥180 ≥180 ≥180
Elongation R.T.(23℃) ≥5 ≥6 ≥8 ≥10 ≥12

IPC-TM-650

2.3.18

H.T.(180℃) ≥5 ≥6 ≥7 ≥8 ≥8
Peel Strength(FR-4) N/mm 0.7 0.8 1.0 1.1 1.2

IPC-TM-650

2.4.8

Ibs/in 4 4.6 5.7 6.3 6.9
Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) 180days /
H.T.(200℃) 60 Minutes /

Standard Width 1290mm,max width 1380(±1)mm,May according to the customer request.
