18um ED Electrolytic Foil Copper for Low Fever Electronic Materials

18um ED Electrolytic Foil Copper for Low Fever Electronic Materials

  • 18um ED Electrolytic Foil Copper for Low Fever Electronic Materials
  • 18um ED Electrolytic Foil Copper for Low Fever Electronic Materials
18um ED Electrolytic Foil Copper for Low Fever Electronic Materials
Product Details:
Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC
Payment & Shipping Terms:
Minimum Order Quantity: 100kg
Price: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Purity: 99.95% Pinholes: None
Anti Oxidation: 180 Degree 60 Minutes, 180 Days 23 Degree Thickness: 1/2 Oz,3/4 Oz,1 Oz,2 Oz,
Color: Red Or Black Elongation: ≥ 1.5%
Tensile Strength: ≥ 160 MPa Peel Strength: ≥ 1 N/mm
Foil Profile: RA≤0.15μm,Rz≤1.7μm Application:: FCCL,FPC
Length Per Roll: 500 - 5000 Meter Inter Diameter: 76 Mm,152 Mm, 3 Inch,6 Inch
High Light:

copper foil sheet roll

,

copper sheet plate

18um ED Electrolytic Foil Copper for Low Fever Electronic Materials



Description:

  • Various kinds of Roughness.
  • Low profile and good peel strength with resin.
  • Good chemical resistance.
  • Foil Thickness: 12 um-70um
  • Foil Width: 10-520 mm
  • Foil Length: 5000 M
  • Internal diameter: 40/76 /152 mm
  • Purity:99.8%



Range of Usage:

  1. Radio frequency cable
  2. Transformer
  3. Lead frame
  4. Copper cladding aluminum
  5. Water heater exchanger
  6. Automotive manufacturers



Application:

  • Low fever electronic materials



Overview:

  • We propose two kinds of copper foils and new production method, aiming at improving productivity and yield in coreless board process.
  • 1,PaCuT
  • PaCuTis the application product of cut foil which shiny side of two Cu sheets are attached to each other by glue.
  • 2,PCS or PCM (Peelable Copper Foil on Shiny side or Matte side)



Package:wooden box



FAQ:

Q1: About sample test ?

A1: we can provide A4 size.



Q2. Can provide TDS?
A2: Yes, we have 100% test and provide technical data sheet before delivery.



Q3. what is your standard width?

A3: we accept customization for the width. Common width is 1290 and 1380mm



Typical Properties of High Coarse Copper Foil

Classification

Unit Requirement Test Method
Foil Designation / H M 1 IPC-4562A
Nominal thickness / 1/2 OZ 3/4 OZ 1 OZ IPC-4562A
Area Weight g/㎡ 150±5 228±8 285±10

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side (Ra) սm ≤0.4 ≤0.4 ≤0.4

IPC-TM-650

2.3.17

Matte side(Rz) um ≤8 ≤10 ≤12
Tensile Strength

R.T.(23℃)



Mpa ≥220 ≥235 ≥280

IPC-TM-650

2.3.18

Elongation

R.T.(23℃)



≥2 ≥3 ≥3

IPC-TM-650

2.3.18

Peel Strength(FR-4) CEM-1 N/mm ≥1.5 ≥1.7 ≥2.0

IPC-TM-650

2.4.8

PTC ≥0.5 ≥0.6 ≥0.8
Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) day 180 or customize /
H.T.(200℃) Minutes 60 or customize /

Standard Width,1280 mm
