Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength

Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength

  • Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength
  • Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength
Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength
Product Details:
Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: RACULP-S-B/G/R
Payment & Shipping Terms:
Minimum Order Quantity: 100kg
Price: Negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Purity: 99.95% Pinholes: None
Storage Condition: T≤25℃,RH≤60%,180 Days Thickness: 9μm,10μm,12μm,15μm,20μm,1/2 Oz,3/4 Oz,1 Oz
Elongation: ≥ 5% Tensile Strength: ≥ 150 MPa
Roughness: RA≤0.2μm Application:: Mylar Tape
Length Per Roll: 500 - 5000 Meter Inter Diameter: 76 Mm,152 Mm,3 Inch,6 Inch,80mm
High Light:

copper foil sheet

,

copper sheet roll

Electric Radiator Rolled Copper Foil More Than 150 MPa Tensile Strength



Quickly Details

  • Double side shiny
  • Thickness:0.009-0.09mm
  • Width: 5-620 mm
  • Length: 500-5000 M
  • ID: 40mm,76 mm,152 mm
  • Alloy: T2,C11000,C1100,C101,E-Cu58
  • Temper: O
  • Area Weight
  • Elongation(%)
  • Tensile Strength(MPa)





Compare between CA copper foil and ED copper foil

  1. Process: rolled copper foil (Rolling process),ED copper foil (Electrodeposition process)
  2. Strength toughness: rolled copper foil is a flaky crystalline structure, so the strength and toughness is better than electrolytic copper foil, so most of the rolling copper foil used in flexible printed circuit boards.
  3. Width: rolling copper foil width ≤ 620mm, electrolytic copper foil width ≤ 1380mm
  4. Density: rolled copper foil higher density, the surface is relatively smooth, conducive to the production of printed circuit board after the rapid transmission of the signal, so high-frequency high-speed transmission, fine lines printed circuit board also used some calendering copper Foil.
  5. Surface treatment width:rolled copper foil be limited by Surface treatment widest effective width of 520mm.



Features:

  1. Eco-friendly products and processes.
  2. Excellent uniformity and infiltration.





Application:

  • Shielding ,LED Light Strip, Camera, Electric Radiator


FAQ:

Q1: What's your guarantee?

A1: All our products have 6 months guarantee after received goods, if any quality problem can contact us.

Q2: What's your delivery time ?

A2: The common delivery time is 5-35 working days. The specific delivery time depends on the items and the quantity of your order.


Q3: What's your minimum order quantity?
A3: The MOQ is 150 kg.



Q4: Can you supply the sample?

A4: We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.



Q5. Do you test all your goods before delivery?
A5: Yes, we have 100% test before delivery.



Q6. what is your standard width?

A6: 520mm and 620mm,we accept customization for the width. we can cut it into any size that you demand after pass discussing.





Thickness 0.01mm 0.018mm 0.035mm Width ≤600mm
Item Unit Parameter
Thickness MM 0.01 0.018 0.035
Grade C1100 C1100 C1100
Copper content % ≥99.95 ≥99.95 ≥99.95
Area Weight g/㎡ 88±4 151±5 301±10
Roughness Ra Um ≤0.15 ≤0.15 ≤0.15
Rz Um ≤1.0 ≤1.0 ≤1.0
Tensile Strength(MP) Processing State Mpa ≥380 ≥400 ≥400
state temper (180℃) Mpa ≥160 ≥160 ≥160
Elongation(%) Processing State % ≥1.3 ≥1.4 ≥1.4
state temper (180℃) % ≥8 ≥10 ≥10
Electrical Performance



Conductivity

20℃ IACS ≥98% ≥98% ≥98%
High temperature oxidation resistance(180℃ 1hour)

Qualified

Qualified

Qualified



Remark:Other thickness products can be customized
