Product Details:
Place of Origin: China
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC
Payment & Shipping Terms:
Minimum Order Quantity: 50kg
Price: Negotiation
Packaging Details: Standard Export Wooden Carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Application:: Flexible Copper Clad Plate, PCB,Electric Vehicles Li-ion Battery,5G Thickness: 4.5um 6um 7um 8um 9um 10um 12um 15um 18um 20um 25um 35um 50um 70um 90um 105um 140um
Width Range: Can Be Cutting As Per Size Request. ID: 76mm,152mm
Lead Time: 7-15days Sample: Can Be Supply
Length: Customized Type: ED Copper Foil,Rolled Copper Foil
High Light:

Electric Vehicles PCB Copper Foil

,

Li-ion Battery PCB Copper Foil

,

Electric Vehicles Battery Copper Foil

Jima Copper is a professional supplier of high-precision copper and copper alloy series of foil roll brand. Jima provided 4-800μm thick copper foil, Maximum width 1580 mm, Jima copper foil production capacity is sufficient, with complete varieties, excellent quality.

Jima specializes in the research, development, promotion and application of new technology of rolling copper foil, and it is equipped with a research center of rolling copper foil engineering technology. Jima copper can stably provide various specifications of high-precision flat foil (hard foil, soft foil, semi-hard foil, etc.) and surface treatment foil (red dumb copper foil, black dumb copper foil, high corrosion resistance rolled copper foil, etc.). The products are widely used in electromagnetic shielding, heat dissipation, graphene conductive film production, aerospace, flexible copper plate, lithium battery, 5G communications, LED, intelligent vehicles, drones, wearable electronics and other fields, which is highly recognized and praised by customers. And it is exported to Korea, Japan, Germany, the United States, Russia, India and other countries.



1. JIMA ED Copper Foil Specification & Aplication

/ Item Typical Thickness Typical Application And Peculiarity
Matte Side Treated THE/High Temperature Elongation Copper Foil 12um 18um 35um 70um 105um Polyimide board, Multilayer board, Middle Tg laminate, Epoxy,CEM-3,FR-4
THE HG Copper Foil 12um 18um 35um 70um 105um High Tg ,lead-free and halogen-free, CEM-3,FR-4,FR-5, hydrocarbon substrate, Multilayer board, HDI, High speed board
THE HC Copper Foil 18um 25um 35um Positive temperature resistance, high peel strength
Low Profile Copper Foil (LP-S-P/B) 12um 18um 25um 35um 50um 70um 105um 2layer FCCL,3L-FPC, EMI, green
Very Low Profile Copper Foil (VLP-S-P/B) 12um 18um 35um 70um 2L/3L-FCCL/FPC, EMI, wireless charging, green, Fine circuit pattern, High frequency board .
T1B-DSP/Hyper Very Low Profile Copper Foil 12um 18um 35um High frequency transmission circuit ,High speed digital, base station/server, PPO/PPE
T1A-DSP 12um 18um 35um High frequency transmission circuit ,High speed digital, base station/server, PPO/PPE
T0A-DSP/5G Copper Foil 12um 18um 35um 5G High frequency board, LCP/MPI/MTPI
Shiny Side Treated RTF/Reverse Treated Copper Foil 12um 18um 35um 70um 105um Multilayer board, high frequency board,EMI
RTF/-LC1 Low Coarsening Reverse Treated Copper Foil 12um 18um 35um 50um 70um 105um High frequency ,Ultra-high frequency ,applying to hydrocarbon board ,High Tg, Fine circuit pattern. Applying to PTFE board .
Low Profile Reverse Treated Copper Foil (LP-D-P/B) 12um 18um 35um 50um 70um 2 layer FCCL,,2L-FPC, EMI, wireless charging, green
RT3-MP/Reverse Treated Copper Foil 12um 18um 35um 70um High frequency board,applying to hydrocarbon board, High Tg,Fine circuit pattern
RT3-X-MP 12um 18um 35um 70um High frequency applying to PTFE board,Fine circuit pattern
RT2A-MP 12um 18um 35um 70um Server/switch/storage, PPO/PPE, Mid-low/ultra-low loss
Untreated Free Profile Copper Foil 9um 12um 18um 35um 70um Graphene carrier, special application
LBC-01/Double side Shiny Copper Foil 4.5um 5um 6um 7um 8um 9um 10um 12um Lithium-ion battery , Notebook PC, Mobile phone, Electric vehicle ,Copper foil capacitor
Double Side Treated Double Side Treated Copper Foil 12um 18um 35um 70um Multilayer board, HDI, special application,
Double Side Rough Copper Foil 9um 10um 12um Lithium-ion battery , Notebook PC, Mobile phone, XEV: Hybrid- Electric Vehicles (HEV);Parallel Hybrid Electric Vehicles (PHEV); Electric Vehicles (EV).



2. JIMA Rolled copper foil

JIMA Copper is a hi-tech enterprise specializing in the production of high-precision copper and rolled foil of copper alloy series. The company has passed ISO9001 international quality management system and ISO14001 international environmental management system certification. With the introduction of international first-class production equipment and technology, the company can produce foil of 4-100 μm thickness and a maximum of 660 mm width, which makes the company the largest in copper foil capacity, the most complete in varieties and the highest in professionalism in rolled copper foil research and production in China.

Specializing in the research, development, promotion and application of new technologies and production of rolled copper foil, JIMA Copper has been recognized as Hi- tech Enterprise, Engineering Technology Research Center of Rolled Copper Foil ,provincial Enterprise Technology Center and is a council unit of China Nonferrous Metal Processing Association. The company can steadily provide various specifications of high-precision plain foil (hard foil, soft foil, semi-hard foil, etc.) and surface treatment foil (copper foil with red matte side, copper foil with black matte side, high corrosion resistance rolled copper foil, etc.).The products are widely used in the fields of electromagnetic shielding, heat dissipation, grapheme conductive film production, aerospace, flexible copper clad plate, lithium battery, 5G communication, LED, intelligent automobile, drone, wearable electronic products, etc., and are highly recognized and praised by customers.

and exported to Korea, Japan, Germany, the United States, Russia, India and other countries

JIMA Rolled Copper Foil Specification & Application

Item Alloy Thickness (um) Width(mm) Application
Rolled copper foil for graphene C1020 12um 18um 25um 35um 50um ≤630 Grapheme conductive film production
Rolled Copper Foil with Black/red treatment C1100 6um 9um 12um 18um 22um 35um 50um 70um ≤630 Flexibility LED,FCCL, Flexible Printed Circuit, flexible copper clad plate,
Plain Copper Foil C1100 6um 9um 12um 18um 35um 50um 70um ≤630

Energy storage,Power ., Electric Vehicles Li-ion Battery, 5G Mobile antenna, Heat dissipation

High corrosion resistance rolled copper foil(RA Copper Foil _with Nickel plating) C1100 12um 18um 25um 35um 50um ≤630 Mess mobile model. will be applied almost of Samsung mobile device



JIMA Copper Plant Show:

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 0

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 1

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 2

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 3

JIMA Copper Foil Photos Show :

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 4

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 5

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 6

JIMA Copper Foil Pacakge Show :

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 7

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 8

Electric Vehicles PCB Copper Foil Li-Ion Battery Copper Foil 9
