Place of Origin: | China |
Brand Name: | JIMA |
Certification: | SGS, ISO,Reach, RoHS |
Model Number: | EDCU-HC |
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | wooden carton |
Delivery Time: | 5-15 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 1000 Ton per month |
Name: | 3oz Shielding Copper Foil 4oz 1320mm Width For RF Shiedlding | Thickness: | 3oz,4oz ,105um,140um |
---|---|---|---|
Application:: | EMI RF Copper Foil,RF Room Shielding | Inter Diameter: | 76mm,152mm |
Sample: | Can Be Supply | Lead Time: | 10-15days |
Highlight: | 3oz adhesive copper foil,w1320mm copper shielding tape,3oz copper shielding tape |
3oz shielding Copper Foil 4oz 1320mm Width For MRI Room Shieding
3oz 4oz 140um Copper Shielding Foil 1320mm Width For MRI Room Shielding
Description:
1. mainly used for MRI room. We have customers In Romania, In Holland, In German, In Turkey, In Russian.
2. For MRI room: 2oz 3oz and 5oz are very hot sale spec.
3. 1320mm/1370mm/1290mm width that's popular in the MRI room
4. Roll ID: 76 mm
5. Thickness :3oz/4oz/105um/140um
6. Application: MRI Room Shieding
Shielded Copper Foil Properties
Quality Items | General Technical Terms | |||||
2oz (70um) |
3oz (105um) |
4oz (140um) |
5oz (175um) |
6oz (210um) |
||
Area Weight g/m2 |
585±25 | 915±45 | 1220±60 | 1525±75 | 1830±90 | |
Tensile Strength kg/mm2 |
Room Temperature | ≥25.0 | ||||
Elongation % |
Room Temperature | ≥5.0 | ||||
Leakage Points points/m2 |
No | |||||
Quality of electrical resistivity Ω·g /m2 |
≤0.162 |
Copper Foil Shielding Features
1. Lightweight (compared with other shielding materials)
2. Copper with 1320mm width or wider , can be more easy to install, especially for roofing, wall and floor.
3. Can be used with either a monolithic RF Floor (moisture resistance) or a modular RF Floor.
4. Copper Serves as an eddy current shield for EMI Protection.
5.RF shielding for MRI rooms is necessary to prevent RF noise from entering into the MRI scanner and distorting the image.
The three main types of shielding used for MRIs are copper, steel, and aluminum. Copper is generally considered the best shielding for MRI rooms.
Our Services
1. can provide sample for testing,
2. can cutting width as request
3. can provide small quanity
4. can packed as request
5. any third inspection is ok .
Copper Foil Producing Process:
Copper Foil Application in different filed
