Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards

Certification
Good quality Rolled Copper Foil for sales
Good quality Rolled Copper Foil for sales
I'm Online Chat Now

Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards

China Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards supplier
Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards supplier Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards supplier

Large Image :  Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards

Product Details:

Place of Origin: china
Brand Name: JIMA
Certification: UL,ROHS,SGS
Model Number: Flexible Copper Clad Laminate

Payment & Shipping Terms:

Minimum Order Quantity: 100square
Price: Negotiation
Packaging Details: wooden carton
Delivery Time: 5- 20days
Payment Terms: T/T, L/C
Supply Ability: 1000square per month
Contact Now
Detailed Product Description
Application:: PCB Board Circuit Board Printed Circuits Board Standard: IPC-4562,IPC9TM-650
Copper Foil Thickness: 0.009mm-0.035mm Color Of Copper: Coffee,Pink,Black
Size: 500*500mm,500*250mm ,can Custom Polyimide Thickness: 0.015mm,0.025mm,0.05mm
Material: Polyimide Film,Copper Foil, Polyimide Film,Copper Foil



FCCL Flexible Copper Clad Laminate for FPC TCP Malti-layer boards



Description

SLP flexible laminates are available in a broad range of copper clad constructions using a wide variety of base dielectrics. These laminates are available in either adhesive based or adhesiveless form.

Adhesive based clads, also known as 3-layer, are made using Polyimide film and are available in sheet form with either SLP FR or LF acrylic adhesive. Also available, under the SLP Brand name, is an epoxy adhesive based 3-layer clad in roll form.

Adhesiveless clads, also known as 2-layer, are available either as double-sided using a lamination based manufacturing process or single sided utilizing cast technologSpecifications.





Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards

Specification

1.Material:PI Film,Copper Foil
2.Adhesiveless&High Temperarature Resistance
3.Certificate:UL
4.Polyimide Thickness​
5.Standard:IPC-4562,IPC9TM-650
6.Copper Foil Thickness
7.Color of copper:Coffee,Pink,Black
8.application​:
High Temperature, FPC, TCP, MCM-L, COF, Rigid flex, Malti-layer boards

9.Polyimide Thickness:0.015mm,0.025mm,0.05mm

10.​Material:Polyimide film,Copper Foil, Polyimide film,Copper Foil



FCCL Products Structure

Products Structure 2Layer 3Layer
Single Side ED or RA Cu ED or RA Cu
Adhesive
PI Film PI or PET Film
Double Side ED or RA Cu ED or RA Cu
PI Film Adhesive
ED or RA Cu PI or PET Film
ED or RA Cu
Covertly   Release Paper
Adhesive
PI or PET film
Bonding Sheet   Release Paper

Adhesive

Release film
Stiffener   Release Paper
Adhesive
PI or PET film
Adhesive
PI or PET film



Application

  • Traditional flex circuits
  • High density flex circuits
  • Chip on film (COF) substrate
  • Chip scale packaging (CSP)
  • Ball grid array (BGA)
  • Tape automatic bonding (TAB)

Key Features

  • Tight overall thickness tolerance for controlled impedance applications
  • Expanded design options for manufacturing yields and signal integrity in high-frequency circuits.
  • Fully compatible with industry fabrication processes.
  • All-Polyimide laminate cores in 7, 8, 9, 10, and 12 mil thickness. Copper choices from 5 micron to 2 oz.
  • Available in standard and custom sizing (up to 100” length)
  • Packaging & Delivery
  • Packaging Details:

    1.Flexible Copper Clad Laminate:
    2.500 copper clad laminator pcb board in one pallet

    Delivery Detail:

    Within 7 working days

Thickness Availability

  Microns (Mils)
Polyimide 25(1), 38(1.5), 50(2), 75(3), 100(4), 125(5), 150(6), 175(7)
  Microns (Oz./sq. ft.)
RA Copper (both sides) 18(1/2), 35(1), 70(2), 105(3), 140(4)
ED Copper (both sides) 9(1/4), 12(1/3), 18(1/2), 35(1), 70(2

Products Classification

Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards



Polyimide Film Copper Clad Laminate For FPC TCP Multi Layer Boards

FAQ

Q1: Can you supply the sample?

A: We can supply samples to check the quality before bulk order. But the price will be sample price not wholesale price.

Q2. Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery

Q3. What is your MOQ?

A: 100square

Q4. Can you provide MTC?

Yes , we can MTC

Q5. Can you cut into small size?

Yes, we can.

Q6: What's your guarantee?

A: All our products have 6 months guarantee after received goods, if any quality problem please contact us.

Q7: What's your delivery time ?

A: The common delivery time is 5-25 days. The specific delivery time depends on the items and the quantity of your order.

Q8:Can you provide sample?

A:we can provide A4 sample as per your thickness

Q9:What’s your MOQ?

A:100square

Quality

our principal manufacturers to ensure the high quality of products in the following aspects:

1.Certification - All of our principle manufacturers are ISO and/or U/L and SGS (RoHS)

approved manufacturers with complete a quality control management system.

2. Standard- All of our principle manufacturers follow industry standards. Such as IPC

standard, GB4588.

3. Global Reputation - All of our principle manufacturers have already exported their

products to oversea customers and/or world-renowned brands with excellent reputations.

4. Credit and Trust - Most of our principle manufactures have had long time business

relationship with us.

5. Competitive Advantage - All the products we represent have competitive advantage

in the market, in terms of technology, pricing, and/or environment protection.
