RCC Red HTE Copper Foil Polyimide Board Suit 12 Mic SGS / RoHS Approval

China RCC Red HTE Copper Foil Polyimide Board Suit 12 Mic SGS / RoHS Approval supplier

Large Image :  RCC Red HTE Copper Foil Polyimide Board Suit 12 Mic SGS / RoHS Approval

Product Details:

Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC

Payment & Shipping Terms:

Minimum Order Quantity: 100kg
Price: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Anti Oxidation: 180 Degree 60 Minutes, 180 Days 23 Degree Thickness: 1/2 Oz,3/4 Oz,1 Oz,2 Oz,
Color: Red Or Black Elongation: ≥ 1.5%

RCC 12 mic HTE red electrolytic copper foil for Polyimide board.



Products Specification:



. Single side side treatment in red.

. Thickness: 12um.

. Width: 5-1380mm.



Feature Description:



1. Perfect normal temperature storage performance.

2. High temperature anti-oxidization performance.

3. High temperature elongation performance.



Products Classify:



The ED copper foils for PCB can be divided into below parts:

(STD-E)- standard electrodeposited copper foil.

(HD-E)-high ductility electrodeposited copper foil.



Products Application:



1. Polyimide board.

2. Epoxy board.



FAQ:



Q1: What's your guarantee?

A: All our products have 6 months guarantee after received goods, if any quality problem can contact us.



Q2: What's your delivery time ?

A: The common delivery time is 5-35 working days. The specific delivery time depends on the items and the quantity of your order.



HTE copper foil with high elongation copper foil at high temperature

Thickness um 9 12 18 25 35 70

IPC 4562

4.6.3.1



Area weight g/m² 80±1 107±3 153± 215±5 285±5 585±8

IPC 4562

4.6.3.2

Roughness (RA) μm 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4

IPC 4562

4.6.9

(RZ) μm <6.0 <6.5 <8.0 <9.0 ≤10.0 <15



Copper≧

% 99.8

IPC 4562

4.6.3.1



Tensile Strength state normal Mpa >300 >300 >300 >300 >300 >280

IPC 4562

4.6.4

state temper (180℃) Mpa >15.0 >18.0 >18.0 >18.0 >18.0 >18.0
ElongationI state normal % >3.0 >3.0 >5.0 >6.0 >10.0 >10.0

IPC 4562

3.5.3

state temper (180℃) % >2.0 >2.5 >2.5 >3.0 >5.0 >5.0
Peel strength N/mm >1.0 >1.05 >1.35 >1.70 >1.8 >2.0

IPC 4562

4.6.7

High temperature oxidation resistance(200℃,

40min)

No color change Standard
Solderability Good Standard
Solderability Good

IPC 4562

4.6.12

3. Standard Width,1295(±1)mm,May according to the customer request tailor.

We test the peel strength with FR-4(Tg140) prepreg ,please reconfirm with your pp.
