5 - 660mm Width Copper Foil For Pcb , Single Side Black Treated Ra Copper Foil

Certification
Good quality Rolled Copper Foil for sales
Good quality Rolled Copper Foil for sales
I'm Online Chat Now

5 - 660mm Width Copper Foil For Pcb , Single Side Black Treated Ra Copper Foil

China 5 - 660mm Width Copper Foil For Pcb , Single Side Black Treated Ra Copper Foil supplier

Large Image :  5 - 660mm Width Copper Foil For Pcb , Single Side Black Treated Ra Copper Foil

Product Details:

Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: RAPCB

Payment & Shipping Terms:

Minimum Order Quantity: 100kg
Price: Negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Thickness: 1/4 Oz,1/2 Oz,3/4 Oz,1 Oz,2 Oz,3 Oz Peel Strength: ≥ 1 N/mm
Foil Profile: RA≤0.2μm Application: PCB CCL
Length Per Roll: 500 - 5000 Meter

0.018mm(18μm,1/2 OZ) single side black treated RA Copper foil For CCL



(Single side black treated within low profile)



Quickly details



. Thickness: 0.018 mm

. Width: 5-660 mm

. Length: 500-5000 M

. ID: 76 mm,152 mm



Features:



. The treated foil in gray or red or back

. Excellent etching performance

. Low profile enables to make fine circuit pattern



Application:



CCL (Copper Clad Laminate),PCB(Printed Circuit board)



· CEM-3

· Auto

· IC Substrate

· High Speed Circuit Material

· RF & Microwave Circuit Material

· Rigid Polyimide



FAQ:



Q1: What's your guarantee?



A: All our products have 6 months guarantee after received goods, if any quality problem can contact us.

Q2: What's your delivery time ?


A: Common delivery time:30 days. we accept 5days when delivery in urgent



Q3: What's your MOQ?


A: The MOQ is 100 kg.



Q4. what is your standard width?



A: treated copper foil width:520mm, double shiny copper foil width: 620mm





TDS for PCB,CCL



Thickness 0.009-0.09mm Width≤520mm
Item Unit Parameter
Thickness MM 0.009 0.012 0.018 0.035 0.07 0.1
Grade C1100 C1100 C1100 C1100 C1100 C1100
Copper content % ≥99.95 ≥99.95 ≥99.95 ≥99.95 ≥99.95 ≥99.95
Area Weight g/㎡ 80±2 107±4 160±5 311±10 623±19 890±27
Roughness (RA) Um ≤0.2 ≤0.2 ≤0.2 ≤0.2 ≤0.2 ≤0.2
Tensile Strength(MP) State normal Mpa ≥380 ≥400 ≥400 ≥420 ≥430 ≥450
State temper (180℃) Mpa ≥160 ≥160 ≥160 ≥170 ≥180 ≥190
Elongation(%) State normal % ≥0.8 ≥1.0 ≥1.2 ≥1.3 ≥1.4 ≥1.5
State temper(180℃) % ≥5 ≥6 ≥8 ≥15 ≥20 ≥25
Peel strength N/mm ≥0.8 ≥1.0 ≥1.4 ≥1.5 ≥1.8 ≥2.0
High temperature oxidation resistance(180℃ 1hour) Qualified Qualified Qualified Qualified Qualified Qualified



Remark:Standard Width,520(±1)mm,accept customization.
