30 Micron Thickness Copper Shielding Foil 99.95% Purity Good Etch Ability

China 30 Micron Thickness Copper Shielding Foil 99.95% Purity Good Etch Ability supplier

Large Image :  30 Micron Thickness Copper Shielding Foil 99.95% Purity Good Etch Ability

Product Details:

Place of Origin: china.Shanghai
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDSHE

Payment & Shipping Terms:

Minimum Order Quantity: 100kg
Price: usd 15-20 /kg
Packaging Details: wooden carton
Delivery Time: 5-18 days
Supply Ability: 1900 Ton per month
Contact Now
Detailed Product Description
Purity: 99.95% Thickness: 1oz,35um,35micron,0.035mm
Splice: ≤2 Application: Shielding Cooper Foil,shielding Application
Max Width: 1360mm,1290mm,1380mm Roll Weight: 150kgs~600kgs
Test Method: IPC 4562 AndIPC-TM-650 Peel Strength: ≥1.6kgf/cm

1oz 30micron thickness electrodeposited electrolytic ED shielding copper foil 0.035mm for Shielding application



Detail Introduction

Max width 1360mm,1290mm,1380mm,standard width is 1290mm,can Custom as per your request
Thickness 1.5oz,50um,50micron,0.05mm
Peel Strength ≥1.6kgf/cm
Internal Diameter of roll 76mm or 152mm,can custom
Splice of roll ≤2
Standard IPC 4562 and IPC-TM-650
Length per roll 500m~5000m
Application 3.shielding copper foil, shielding material

30 Micron Thickness Copper Shielding Foil 99.95% Purity Good Etch Ability





  (1) he treated foil in gray or red
Characteristics
(2) High peel strength
  (3) Good etch ability
  (4) Excellent adhesion to etching resis



​Packackage and Mark  :standard export sea wooden box .

30 Micron Thickness Copper Shielding Foil 99.95% Purity Good Etch Ability



COA of Shielding ED Electromagnetic Copper Foil

Classification Unit Requirement Test Method
Foil Designation / T H M 1 2 3 IPC-4562A
Nominal thickness / 12um 1/2 OZ 3/4 OZ

1

OZ

2

OZ

3

OZ

IPC-4562A
Area Weight g/㎡ 107±4 153±5 228±8 285±10 580±15 860±20

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side (Ra) սm ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4

IPC-TM-650

2.3.17

Matte side(Rz) um ≤6 ≤8 ≤10 ≤10 ≤15 ≤20
Tensile Strength

R.T.(23℃)



Mpa ≥150 ≥220 ≥235 ≥280 ≥280 ≥280

IPC-TM-650

2.3.18

Elongation

R.T.(23℃)



≥2 ≥3 ≥3 ≥4 ≥4 ≥4

IPC-TM-650

2.3.18

Subject Ω.g/㎡ ≤0.170 ≤0.166 ≤0.162 ≤0.162 ≤0.162 ≤0.162

IPC-TM-650

2.5.14

Peel Strength(FR-4) N/mm ≥1.0 ≥1.3 ≥1.6 ≥1.6 ≥2.1 ≥2.1

IPC-TM-650

2.4.8

Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) day 180 /
H.T.(200℃) Minutes 60

1. Standard Width,1295(±1)mm,Max width is 1380mm,May according to the customer request .


FAQ:

Q1>.:Can you provide COA?
Yes , we can.
Q2>: Can we come to China visit factory ?
Yes ,you can .
Q3>: Can you cut into small size?
Yes, we can.as request
Q4>: What's your guarantee?
A: All our products have 6 months guarantee after received goods, if any quality problem pls contact us.
Q5>: What's your delivery time ?
A: The common delivery time is 5-35 working days. The specific delivery time depends on the items and the quantity of your order.
Q6>: What's your minimum order quantity?
A: The MOQ is 150 kg.
Q7>: Can you supply the sample?
A: We can supply samples to check the quality before bulk order. or also can provide a4sample as your thickness request.
Q8>. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q9>. what is your standard width and Max width?
A: 1290mm and 1380mm,we accept customization for the width. we can cut it into any size .

Keep the dry environment,and is better use it in 30days.
