Red Matte Treated Electrolytic Copper Foil 5 - 1380 Mm Width 99.95% Purity

China Red Matte Treated Electrolytic Copper Foil 5 - 1380 Mm Width 99.95% Purity supplier

Large Image :  Red Matte Treated Electrolytic Copper Foil 5 - 1380 Mm Width 99.95% Purity

Product Details:

Place of Origin: china
Brand Name: JIMA
Certification: SGS, ISO,Reach, RoHS
Model Number: EDCU-HC

Payment & Shipping Terms:

Minimum Order Quantity: 100kg
Price: negotiation
Packaging Details: wooden carton
Delivery Time: 5-15 days
Payment Terms: T/T, L/C
Supply Ability: 1000 Ton per month
Contact Now
Detailed Product Description
Purity: 99.95% Pinholes: None
Color: Red Or Black Elongation: ≥ 1.5%

12 um red matte treated VLP electrolytic copper foil for Chip on flex (COF) for LED.



Product details introduction.



Matte side treatment in back/red color.

Thickness: 12µm.

Width: 5-1380 mm.



Red Matte Treated Electrolytic Copper Foil 5 - 1380 Mm Width 99.95% Purity



Products Performance.



1. The treated foil in gray or red.

2. High profile with properties of LP-S-B/R suitable for FCCL.

3. Grain structure of copper foil leads to high flexibility.



VLP copper foil Application:



1. Casting and lamination type FCCL.

2. Super fine pattern FPC.



RFQ



Q1: What's your guarantee?



All our products have 6 months guarantee after received goods, if any quality problem please free contact us.



Q2: What's your minimum order quantity?



The MOQ is 150 kg.



Q3. what is your standard width?



Standard width is 1290mm,we accept customization for the width. we can cut it into any size .





Typical properties of VLP-S-B/R copper foil(for FPC or inner layer of HDI).



Classification



Unit Requirement Test Method
Foil Designation /   1 H M 1 IPC-4562A
Nominal thickness / 10um 12um 1/2 OZ (18um) 3/4 OZ(25um) 1 OZ(35um) IPC-4562A
Area Weight g/㎡ 98±4 107±4 153±5 228±8 285±10

IPC-TM-650

2.2.12.2

Purity ≥99.8

IPC-TM-650

2.3.15

Foil Profile Shiny side(Ra) սm ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5

IPC-TM-650

2.3.17

Matte side(Rz) um ≤2.5 ≤2.5 ≤2.5 ≤2.5 ≤2.5
Tensile Strength R.T.(23℃) Mpa ≥300 ≥300 ≥300 ≥300 ≥300

IPC-TM-650

2.3.18

H.T.(180℃) Mpa ≥200 ≥200 ≥200 ≥200 ≥200
Elongation R.T.(23℃) ≥4 ≥5 ≥6 ≥8 ≥10

IPC-TM-650

2.3.18

H.T.(180℃) ≥5 ≥6 ≥7 ≥8 ≥8
Peel Strength(FR-4) N/mm ≥0.8

IPC-TM-650

2.4.8

Ibs/in ≥4.6
Pinholes&porosity Number No

IPC-TM-650

2.1.2

Anti-oxidization R.T.(23℃) 180days /
H.T.(200℃) 60 Minutes /

4. Standard Width 1295mm,max width 1380(±1)mm,May according to the customer request tailor.We test the peel strength with PI ,please reconfirm with your pp.
